CE Certification Copper Bonded Earth Rods Suppliers, Factories

Main technical parameters and specifications

Copper layer thickness: â‰¥0.254mm (UL standard â‰¥0.254mm)

Tensile strength: â‰¥600N/mmÂ².

Copper layer plasticity: grounding rod (wire) bending into a U-shaped, no cracks in the corner of the outer edge.

Copper layer bonding: by the adhesion test, in addition to the vise jaws bite at the flaking copper layer, the rest of the copper-steel bonding is good, there is no stripping phenomenon.

Send Inquiry

Product Description

Threaded Copper Bonded Earth Rods

Part No.	Nominal diameter	Length	Thread 'B'	Shank 'A'	Weight each
ERT1112*	1/2"	1200mm	1/2"	11mm	0.89kg
ERT1115*	1/2"	1500mm	1/2"	11mm	1.12kg
ERT1118*	1/2"	1800mm	1/2"	11mm	1.34kg
ERT1212	1/2"	1200mm	9/16"	12.7mm	1.18kg
ERT1215	1/2"	1500mm	9/16"	12.7mm	1.55kg
ERT1218	1/2"	1800mm	9/16"	12.7mm	1.76kg
ERT1224	1/2"	2400mm	9/16"	12.7mm	2.36kg
ERT1412	5/8"	1200mm	5/8"	14.2mm	1.53kg
ERT1415	5/8"	1500mm	5/8"	14.2mm	1.88kg
ERT1418	5/8"	1800mm	5/8"	14.2mm	2.29kg
ERT1421	5/8"	2100mm	5/8"	14.2mm	2.51kg
ERT1424	5/8"	2400mm	5/8"	14.2mm	3.00kg
ERT1430	5/8"	3000mm	5/8"	14.2mm	3.79kg
ERT1615	16mm	1500mm	M18	16mm	2.37kg
ERT1618	16mm	1800mm	M18	16mm	2.84kg
ERT1624	16mm	2400mm	M18	16mm	3.79kg
ERT1630	16mm	3000mm	M18	16mm	4.73kg
ERT1712	3/4"	1200mm	3/4"	17.2mm	2.19kg
ERT1715	3/4"	1500mm	3/4"	17.2mm	2.73kg
ERT1718	3/4"	1800mm	3/4"	17.2mm	3.27kg
ERT1721	3/4"	2100mm	3/4"	17.2mm	3.83kg
ERT1724	3/4"	2400mm	3/4"	17.2mm	4.35kg
ERT1730	3/4"	3000mm	3/4"	17.2mm	5.44kg

Thread and Shank Diameters

The thread rolling process raises the surface of the rod so that thread diameter (B) is greater than shank diameter (A). These copper bond earth rods are made by molecularly bonding 99.9% pure electrolytic copper on to a low carbon steel core, offering an economical and high-quality solution.

Copper thickness standard: 250 microns (Custom thickness available upon request).
Compliant with BS EN 50164-2, BS7430, and UL467.
Fittings compliant with BS EN 50164-1.

Unthreaded Copper Bonded Earth Rods

Part No.	Diameter	Length	Weight each
ER912	9.0mm	1200mm	0.62kg
ER1212	12.7mm	1200mm	1.18kg
ER1215	12.7mm	1500mm	1.55kg
ER1218	12.7mm	1800mm	1.76kg
ER1224	12.7mm	2400mm	2.36kg
ER1412	14.2mm	1200mm	1.53kg
ER1415	14.2mm	1500mm	1.88kg
ER1418	14.2mm	1800mm	2.29kg
ER1420	14.2mm	2000mm	2.51kg
ER1421	14.2mm	2100mm	2.68kg
ER1424	14.2mm	2400mm	3.00kg
ER1430	14.2mm	3000mm	3.79kg
ER1612	16.0mm	1200mm	1.90kg
ER1615	16.0mm	1500mm	2.37kg
ER1618	16.0mm	1800mm	2.84kg
ER1620	16.0mm	2000mm	3.16kg
ER1624	16.0mm	2400mm	3.79kg
ER1630	16.0mm	3000mm	4.73kg
ER1712	17.2mm	1200mm	2.19kg
ER1715	17.2mm	1500mm	2.73kg
ER1718	17.2mm	1800mm	3.27kg
ER1720	17.2mm	2000mm	3.64kg
ER1721	17.2mm	2100mm	3.83kg
ER1724	17.2mm	2400mm	4.35kg
ER1730	17.2mm	3000mm	5.44kg

Made by molecularly bonding 99.9% pure electrolytic copper to a low carbon steel core. These rods provide exceptional conductivity and corrosion resistance.

Standard Copper thickness: 250 microns.
Compliant with BS EN 50164-2, BS7430, and UL467 standards.

Solid Copper And Stainless Steel Earth Rods

Solid Copper Rod

Part No.	Diameter	Length	Weight each
CER1212	12.7mm	1200mm	1.35kg
CER1215	12.7mm	1500mm	1.69kg
CER1412	14mm	1200mm	1.64kg
CER1415	14mm	1500mm	2.05kg
CER1512	15mm	1200mm	1.88kg
CER1515	15mm	1500mm	2.35kg
CER1530	15mm	3000mm	4.70kg
CER2012	20mm	1200mm	3.34kg

Solid Copper Rod Kit

Part No.	Diameter	Length	Weight each
CER1512–kit	15mm	8 ft(2400)mm	3.82kg
CER2012–kit	20mm	8 ft(2400)mm	6.79kg

Stainless Steel Rod

Part No.	Diameter	Length	Weight each
SER1612	16mm	1200mm	1.87kg
SER1615	16mm	1500mm	2.34kg
SER1630	16mm	3000mm	4.68kg
SER2015	20mm	1500mm	3.65kg
SER2030	20mm	3000mm	7.30kg

Application Notes:

Solid Copper: Ideal for aggressive soil conditions (e.g., high salt content) due to superior corrosion resistance.

Stainless Steel: Used to overcome galvanic corrosion between dissimilar metals. Highly resistant and durable.

Kits: Include 2×1200mm rods, coupling dowel, driving stud, and spike to make an 8 ft rod.

Copper Cladded Non Magnetic Steel Ground Rods

Part No.	Rod Dia.	Length	Copper tube thickness
CCR–1212	12.5mm	1200mm	≥1.5mm
CCR–1312	13mm	1200mm	≥1.5mm
CCR–1412	14mm	1200mm	≥1.5mm
CCR–1415	14mm	1500mm	≥1.5mm
CCR–1615	16mm	1500mm	≥1.5mm
CCR–1715	17.2mm	1500mm	≥1.5mm

Constructed from 99.9% pure electrolytic copper tube and non-magnetic steel. With a copper thickness of over 1.5mm, these rods provide performance comparable to pure copper ground rods with low resistance and high conductivity.

Frequently Asked Questions (FAQ)

What is the advantage of molecularly bonding copper to the steel core?

Molecular bonding ensures that the copper layer will not slip or crack when the rod is driven into the ground, providing long-lasting corrosion protection and consistent electrical conductivity.

Which soil conditions require solid copper earth rods?

Solid copper rods are recommended for highly aggressive environments, such as coastal areas with high salt content or soils with high chemical acidity, where standard rods might corrode faster.

What standards do your earth rods comply with?

Our products are manufactured to meet international standards including BS EN 50164-2, BS7430, and UL467, ensuring safety and reliability in grounding systems.

Why is the thread diameter larger than the shank diameter on threaded rods?

This is a result of the thread rolling process, which strengthens the threads and ensures they are robust enough to maintain a secure connection during installation and throughout the system's lifespan.

Are custom copper plating thicknesses available?

Yes, while our standard copper thickness is 250 microns, we can provide alternative plating thicknesses based on specific project requirements and technical specifications.

What is included in the earth rod kits?

The kits typically include two 1200mm rods, a coupling dowel, a driving stud, and a spike, allowing for the easy assembly of an 8 ft grounding rod on-site.
