| Code Name | Old Code Name | Sectional Area (mm²) | Wire Diameter & Stranding | Diameter of Conductor (mm) | Linear Mass (kg/km) | Rated Strength (kN) | Max D.C. Resistance at 20℃ (Ω/km) | |||||
| Al-alloy | Steel | Total | Al-alloy | Steel | ||||||||
| mm² | mm² | mm² | mm | No | mm | No | mm | kg/km | kN | Ohms/km | ||
| 15-AL 3/3-ST1A | 16/2.5 | 15.3 | 2.5 | 17.8 | 1.80 | 6 | 1.80 | 1 | 5.4 | 61.6 | 7.48 | 2.18 |
| 24-AL 3/4-ST1A | 25/4 | 23.9 | 4.0 | 27.8 | 2.25 | 6 | 2.25 | 1 | 6.8 | 96.3 | 11.71 | 1.3952 |
| 34-AL 3/6-ST1A | 35/6 | 34.4 | 5.7 | 40.1 | 2.70 | 6 | 2.70 | 1 | 8.1 | 138.7 | 16.85 | 0.9689 |
| 44-AL 3/32-ST1A | 44/32 | 44.0 | 31.7 | 75.6 | 2.00 | 14 | 2.40 | 7 | 11.2 | 369.3 | 50.27 | 0.7625 |
| 48-AL 3/8-ST1A | 50/8 | 48.3 | 8.0 | 56.3 | 3.20 | 6 | 3.20 | 1 | 9.6 | 194.8 | 23.66 | 0.6898 |
| 51-AL 3/30-ST1A | 50/30 | 51.2 | 29.8 | 81.0 | 2.33 | 12 | 2.33 | 7 | 11.7 | 374.7 | 50.24 | 0.6547 |
| 70-AL 3/11-ST1A | 70/12 | 69.9 | 11.4 | 81.3 | 1.85 | 26 | 1.44 | 7 | 11.7 | 282.2 | 33.99 | 0.4791 |
| 94-AL 3/15-ST1A | 95/15 | 94.4 | 15.3 | 109.7 | 2.15 | 26 | 1.67 | 7 | 13.6 | 380.6 | 45.82 | 0.3547 |
| 97-AL 3/56-ST1A | 95/55 | 96.5 | 56.3 | 152.8 | 3.20 | 12 | 3.20 | 7 | 16.0 | 706.8 | 94.75 | 0.3471 |
| 106-AL3/76-ST1A | 105/75 | 105.7 | 75.5 | 181.2 | 3.10 | 14 | 2.25 | 19 | 17.5 | 885.3 | 120.14 | 0.3174 |
| 122-AL3/20-ST1A | 120/20 | 121.6 | 19.8 | 141.4 | 2.44 | 26 | 1.90 | 7 | 15.5 | 491 | 59.14 | 0.2754 |
| 122-AL 3/71-ST1A | 120/70 | 122.1 | 71.3 | 193.4 | 3.60 | 12 | 3.60 | 7 | 18.0 | 894.5 | 119.12 | 0.2742 |
| 128-AL 3/30-ST1A | 125/30 | 127.9 | 29.8 | 157.8 | 2.33 | 30 | 2.33 | 7 | 16.3 | 587 | 72.8 | 0.2621 |
| 149-AL 3/24-ST1A | 150/25 | 148.9 | 24.2 | 173.1 | 2.70 | 26 | 2.10 | 7 | 17.1 | 600.8 | 72.36 | 0.2249 |
| 172-AL 3/40-ST1A | 170/40 | 171.8 | 40.1 | 211.8 | 2.70 | 30 | 2.70 | 7 | 18.9 | 788.2 | 97.75 | 0.1952 |
| 184-AL 3/30-ST1A | 185/30 | 183.8 | 29.8 | 213.6 | 3.00 | 26 | 2.33 | 7 | 19.0 | 741 | 89.22 | 0.1822 |
| 209-AL 3/34-ST1A | 210/35 | 209.1 | 34.1 | 243.2 | 3.20 | 26 | 2.49 | 7 | 20.3 | 844.1 | 101.67 | 0.1601 |
| 212-AL 3/49-ST1A | 210/50 | 212.1 | 49.5 | 261.5 | 3.00 | 30 | 3.00 | 7 | 21.0 | 973.1 | 120.68 | 0.1581 |
| 231-AL 3/30-ST1A | 230/30 | 230.9 | 29.8 | 260.8 | 3.50 | 24 | 2.33 | 7 | 21.0 | 870.9 | 103.08 | 0.1449 |
| 243-AL 3/39-ST1A | 240/40 | 243.1 | 39.5 | 282.5 | 3.45 | 26 | 2.68 | 7 | 21.8 | 980.1 | 118.02 | 0.1378 |
| 264-AL3/34-ST1A | 265/35 | 263.7 | 34.1 | 297.7 | 3.74 | 24 | 2.49 | 7 | 22.4 | 994.4 | 117.71 | 0.1269 |
| 304-AL 3/49-ST1A | 300/50 | 304.3 | 49.5 | 353.7 | 3.86 | 26 | 3.00 | 7 | 24.5 | 1227.3 | 147.79 | 0.1101 |
| 305-AL3/39-ST1A | 305/40 | 304.6 | 39.5 | 344.1 | 2.68 | 54 | 2.68 | 7 | 24.1 | 1151.2 | 136.12 | 0.1101 |
| 339-AL 3/30-ST1A | 340/30 | 339.3 | 29.8 | 369.1 | 3.00 | 48 | 2.33 | 7 | 25.0 | 1171.2 | 134.94 | 0.0988 |
| 382-AL 3/49-ST1A | 380/50 | 381.7 | 49.5 | 431.2 | 3.00 | 54 | 3.00 | 7 | 27.0 | 1442.5 | 170.56 | 0.0879 |
| 386-AL 3/34-ST1A | 385/35 | 386.0 | 34.1 | 420.1 | 3.20 | 48 | 2.49 | 7 | 26.7 | 1333.6 | 153.69 | 0.0868 |
| 434-AL 3/56-ST1A | 435/55 | 434.3 | 56.3 | 490.6 | 3.20 | 54 | 3.20 | 7 | 28.8 | 1641.3 | 194.06 | 0.0772 |
| 449-AL 3/39-ST1A | 450/40 | 448.7 | 39.5 | 488.2 | 3.45 | 48 | 2.68 | 7 | 28.7 | 1549.1 | 178.48 | 0.0747 |
| 490-AL 3/64-ST1A | 490/65 | 490.3 | 63.6 | 553.8 | 3.40 | 54 | 3.40 | 7 | 30.6 | 1852.9 | 219.07 | 0.0684 |
| 550-AL 3/71-ST1A | 550/70 | 549.7 | 71.3 | 620.9 | 3.60 | 54 | 3.60 | 7 | 32.4 | 1851.4 | 245.6 | 0.061 |
| 562-AL3/49-ST1A | 560/50 | 561.7 | 49.5 | 611.2 | 3.86 | 48 | 3.00 | 7 | 32.2 | 1939.5 | 223.48 | 0.0597 |
| 679-AL 3/86-ST1A | 680/85 | 678.6 | 86.0 | 764.5 | 4.00 | 54 | 2.40 | 19 | 36.0 | 2547.6 | 300.84 | 0.0494 |
